商品の詳細:
|
| Part Number: | BSP613P | Transistor Polarity:: | P-Channel |
|---|---|---|---|
| Number of Channels:: | 1 Channel | Vds - Drain-Source Breakdown Voltage:: | 60 V |
| Id - Continuous Drain Current:: | 2.9 A | Rds On - Drain-Source Resistance:: | 130 mOhms |
BSP613P Integrated Circuit Chip 60V P-Channel Enhancement SIPMOS Power MOSFET Transistor
Product Description Of BSP613P
BSP613P is 60V P-Channel Enhancement SIPMOSPower MOSFET Transistor.
Specifications Of BSP613P
|
|
P-Channel |
|
|
1 Channel |
|
|
60 V |
|
|
2.9 A |
|
|
130 mOhms |
|
|
- 20 V, + 20 V |
|
|
2.1 V |
|
|
22 nC |
|
|
- 55 C |
|
|
+ 150 C |
|
|
1.8 W |
|
Fall Time: |
7 ns |
|
Forward Transconductance - Min: |
2.7 S |
|
Height: |
1.6 mm |
|
Length: |
6.5 mm |
|
Product Type: |
MOSFETs |
|
Rise Time: |
9 ns |
|
Typical Turn-Off Delay Time: |
26 ns |
|
Typical Turn-On Delay Time: |
6.7 ns |
|
Width: |
3.5 mm |
|
Unit Weight: |
112 mg |
Features Of BSP613P
Enhancement mode
Normal level
Avalanche rated
Fast switching
dv/dt rated
Pb-free lead-plating
RoHS compliant, halogen-free
Qualified according to Automotive Std
PPAP capable
Benefits Of BSP613P
Low RDS(on) for high efficency
Small packages save PCB space
Best-in-class quality and reliability
Applications Of BSP613P
Electronic stability control
Electric power steering (EPS)
EV traction inverter
Programmable logic controller (PLC)
