MWCT2016SHVPA Wireless Communication Module Multi-Coil Wireless Charging Transmitter

MWCT2016SHVPA Wireless Communication Module Multi-Coil Wireless Charging Transmitter

Product Description Of MWCT2016SHVPA
MWCT2016SHVPA multi-coil wireless charging transmitter ICs provide complete controller functionality with AUTOSAR® SW to implement a wireless charging transmitter solution in an automotive environment. With integrated security element and dual core is perfect solution for QI 2.x application

Features Of MWCT2016SHVPA
Compliant with the latest version WPC Qi power class 0 specification's power transmitter designs
AUTOSAR SW compliant 4.4 or R21-11
Advanced on chip digital demodulation
HSE security engine - AES-128/192/256, RSA, ECC, secure boot and key storage for QI auth
System supports ultra-low standby power mode
Advanced Q-factor and Power Loss FOD methods
Temperature sensing
CAN FD/I²C/SCI/SPI interfaces
Secure Firmware (FW) updates in the field (OTA with double banking)
Compliant with the latest version WPC Qi power class 0 specification's power transmitter designs
MWCT2016S and MWCT2D1xS supports two isolated channels - two phones simultaneous charging
Support wide transmitter DC input voltage range from 5 V to 48 V (Clean EMC)
Low power object detection with NCF3321
Supports operation frequency dithering technology to eliminate AM band interference and improve EMC
Over-voltage/current/temperature protection
S32 Design Studio IDE – Eclipse, GCC and debugger, 3rd party support
Real-Time Drivers – free of charge (AUTOSAR and non-AUTOSAR), ASIL B
Security firmware – NXP provided, field upgradeable
S32 Safety Software Framework (SAF) and Structural Core Self-Test (SCST) library
Safety Peripheral Drivers
