AS5145A-HSSM Sensor IC 12-Bit Programmable Magnetic Rotary Encoder SSOP-16
Product Description
AS5145A-HSSM is a contactless magnetic rotary encoder for accurate angular measurement over a full turn of 360 degrees. It is a system-on-chip, combining integrated Hall elements, analog front end and digital signal processing in a single device. To measure the angle, only a simple two-pole magnet, rotating over the center of the chip, is required. The magnet can be placed above or below the IC.
Specifications
| Encoder Type |
Magnetic |
| Output Type |
Quadrature (Incremental) |
| Pulses per Revolution |
1024 |
| Voltage - Supply |
3V ~ 3.6V, 4.5V ~ 5.5V |
| Actuator Type |
External Magnet, Not Included |
Features
- Contactless high resolution rotational position encoding over a full turn of 360 degrees
- Two digital 12-bit absolute outputs:
- Serial interface
- Pulse width modulated (PWM) output
- Three incremental outputs
- Quadrature A/B/I (10 or 12 bit) and Index output signal (preprogrammed versions available AS5145A for 10-bit and AS5145B for 12-bit)
- User programmable zero position
- Failure detection mode for magnet placement, monitoring, and loss of power supply
- Red-Yellow-Green indicators display placement of magnet in Z-axis
- Serial read-out of multiple interconnected AS5145 devices using Daisy Chain mode
- Tolerant to magnet misalignment and gap variations
- Wide temperature range: -40ºC to +150ºC
- Fully automotive qualified to AEC-Q100, grade 0
- Small Pb-free package: SSOP 16 (5.3mm x 6.2mm)
Applications
- Industrial applications like contactless rotary position sensing and robotics
- Automotive applications:
- Steering wheel position sensing
- Transmission gearbox encoder
- Head light position control
- Torque sensing
- Valve position sensing
- Replacement of high end potentiometers
