商品の詳細:
|
| 部品番号: | ADG4612BRUZ | チャネルの数:: | 4チャンネル |
|---|---|---|---|
| 構成：: | 4×SPST | オン抵抗 - 最大:: | 6.1 オーム |
| 供給電圧-min：: | 3 v | 供給電圧-max：: | 12 v |
ADG4612BRUZ Integrated Circuit Chip Quad SPST Switches With 5Ω On Resistance
Product Description Of ADG4612BRUZ
ADG4612BRUZ contain four independent single-pole/ single-throw (SPST) switches. The ADG4612BRUZ switches are turned on with Logic 1 on the appropriate control input. Each switch conducts equally well in both directions when on and has an input signal range that extends to the supplies.
Specifications Of ADG4612BRUZ
|
Switch Circuit |
SPST - NO |
|
Multiplexer/Demultiplexer Circuit |
1:1 |
|
Number of Circuits |
4 |
|
On-State Resistance (Max) |
5.1Ohm |
|
Channel-to-Channel Matching (ΔRon) |
50mOhm |
|
Voltage - Supply, Single (V+) |
3V ~ 12V |
|
Voltage - Supply, Dual (V±) |
±3V ~ 5.5V |
|
Switch Time (Ton, Toff) (Max) |
73ns, 91ns |
|
-3db Bandwidth |
250MHz |
|
Charge Injection |
292pC |
|
Channel Capacitance (CS(off), CD(off)) |
11.5pF, 11.5pF |
|
Current - Leakage (IS(off)) (Max) |
10nA |
|
Crosstalk |
-74dB @ 1MHz |
|
Operating Temperature |
-40°C ~ 105°C (TA) |
Features Of ADG4612BRUZ
Power Off Protection
Switch guaranteed OFF with no power supplies present Inputs are high impedance with no power
Switch turns OFF if input > VDD + VT
Over-voltage protection up to +16V
PSS Robust
Negative Signal Capability passes signals down to -5.5V
6.1Ω Max On Resistance
1.4Ω On Resistance Flatness
±3V to ±5.5V dual supply
3V to 12 V single supply
3 V logic-compatible inputs
Rail-to-rail operation
16-lead TSSOP and 16 lead 3mm x 3mm LFCSP
Applications Of ADG4612BRUZ
Hot swap applications
Data acquisition systems
Battery-powered systems
Automatic test equipment
Communication systems
Relay Replacement
