商品の詳細:
|
| 部品番号: | BTS5200-4EKA | タイプ: | 高い側面 |
|---|---|---|---|
| 出力電流: | 800 Ma | 現在の制限: | 5.6 A |
| 最高抵抗-: | 400のmOhms | 稼働電源電圧: | 5ボルトから28ボルト |
BTS5200-4EKA Integrated Circuit Chip Quad Channel Smart High-Side Switch PG-DSO-14
Product Description Of BTS5200-4EKA
BTS5200-4EKA is a 200 mΩ quad channel Smart High-Side Switch, embedded in a PG-DSO-14-48- EP, Exposed Pad package, with protective functions and diagnosis.
BTS5200-4EKA Power transistor is built by an N-channel vertical power MOSFET with charge pump. The device is integrated in Smart6 technology. It is specially designed to drive lamps up to R5W, as well as LEDs in the harsh automotive environment.
Specification Of BTS5200-4EKA
|
Series
|
PROFET®
|
|
Switch Type
|
General Purpose
|
|
Number of Outputs
|
4
|
|
Ratio - Input:Output
|
1:1
|
|
Output Configuration
|
High Side
|
|
Output Type
|
N-Channel
|
|
Interface
|
Parallel
|
|
Voltage - Load
|
5V ~ 28V
|
|
Voltage - Supply (Vcc/Vdd)
|
Not Required
|
|
Current - Output (Max)
|
800mA
|
|
Rds On (Typ)
|
200mOhm
|
|
Input Type
|
Non-Inverting
|
|
Fault Protection
|
Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
|
|
Operating Temperature
|
-40°C ~ 150°C (TJ)
|
|
Mounting Type
|
Surface Mount
|
|
Supplier Device Package
|
PG-DSO-14-48-EP
|
|
Package / Case
|
14-SOIC (0.154", 3.90mm Width) Exposed Pad
|
Features Of BTS5200-4EKA
Quad channel device
Very low stand-by current
3.3 V and 5 V compatible logic inputs
Electrostatic discharge protection (ESD)
Optimized electromagnetic compatibility
Logic ground indep from load ground
Low power DMOS leakage I in OFF state
Applications Of BTS5200-4EKA
Automotive body control module (BCM)
Automotive battery management system (BMS) - high-voltage
EV traction inverter
On-board charging (OBC)
Domestic robots
Other Electronic Components In Stock
| Part Number | Package |
| IHW20N120R5 | TO-247-3 |
| IKQ120N60T | TO-247-3 |
| IKD15N60R | TO-252-3 |
| IHW30N120R5 | TO-247-3 |
| IHW40N120R5 | TO-247-3 |
| IKW40N65F5 | TO-247-3 |
| IKW40N65ES5 | TO-247-3 |
| IHW40N135R5 | TO-247-3 |
| IKW15N120H3 | TO-247-3 |
| IKW50N60H3 | TO-247-3 |
| IKY40N120CS6 | TO-247-4 |
| IKW25N120H3 | TO-247-3 |
| IKZA75N65SS5 | TO-247-4 |
| IKD10N60RC2 | TO-252-3 |
| IKD10N60RFATMA1 | TO-252-3 |
| IKD15N60RC2ATMA1 | TO-252-3 |
| IGB30N60H3ATMA1 | TO-263-3 |
| IGB50N65S5ATMA1 | TO-263-3 |
| IKB40N65ES5ATMA1 | TO-263-3 |
| IGP30N60H3XKSA1 | TO-220-3 |
| IGB50N60TATMA1 | TO-263-3 |
| IGW20N60H3FKSA1 | TO-247-3 |
| IHW30N65R6XKSA1 | TO-247-3 |
| IKW30N65WR5XKSA1 | TO-247-3 |
| IHW30N65R5XKSA1 | TO-247-3 |
| IKWH30N65WR5XKSA1 | TO-247-3 |
| IKW30N60H3FKSA1 | TO-247-3 |
| IHW50N65R6XKSA1 | TO-247-3 |
| IKWH40N65WR6XKSA1 | TO-247-3 |
| IKWH50N65WR6XKSA1 | TO-247-3 |
