商品の詳細:
|
| 部品番号: | DP83848KSQ | スタンダード: | 10/100Base-T |
|---|---|---|---|
| データレート: | 10 mb/s、100 mb/s | インターフェイスタイプ: | MII、RMII、SNI |
| PD-電力散逸: | 267 MW | タイプ: | イーサネット トランシーバー |
DP83848KSQ Ethernet IC Ethernet Transceivers 10/100Mbps Ethernet PHY Transceiver
Product Description Of DP83848KSQ
DP83848KSQ is 10/100-Mbps Ethernet PHY transceiver in a 40-pin QFN package, it addresses the quality, reliability and small form factor required for space sensitive applications in embedded systems.The DP83848KSQ also offers Auto-MDIX to remove cabling complications.
Specification Of DP83848KSQ
|
Type
|
Transceiver
|
|
Protocol
|
Ethernet
|
|
Number of Drivers/Receivers
|
1/1
|
|
Voltage - Supply
|
3V ~ 3.6V
|
|
Operating Temperature
|
-40°C ~ 85°C
|
|
Mounting Type
|
Surface Mount
|
|
Package / Case
|
40-WFQFN Exposed Pad
|
|
Supplier Device Package
|
40-WQFN (6x6)
|
Features Of DP83848KSQ
Low-Power 3.3-V, 0.18-µm CMOS Technology
Auto-MDIX for 10/100 Mb/s
Energy Detection Mode
3.3-V MAC Interface
RMII Rev. 1.2 Interface (configurable)
MII Interface
MII Serial Management Interface (MDC and MDIO)
IEEE 802.3 Auto-Negotiation and Parallel Detection
IEEE 802.3 ENDEC, 10BASE-T Transceivers and Filters
IEEE 802.3 PCS, 100BASE-TX Transceivers and Filters
Integrated ANSI X3.263 Compliant TP-PMD Physical Sub-Layer with Adaptive Equalization and Baseline Wander Compensation
Error-Free Operation Beyond 137 Meters
ESD Protection – Greater than 4 kV Human Body Model
Single Register Access for Complete PHY Status
10/100 Mb/s Packet BIST (Built-in Self Test)
Applications Of DP83848KSQ
Peripheral Devices
Mobile Devices
