RBN75H65T1FPQ-A0 Integrated Circuit Chip 650V 75A Trench IGBT Transistors TO-247-3
Product Description Of RBN75H65T1FPQ-A0
RBN75H65T1FPQ-A0 is 650V, 75A Trench Insulated-gate bipolar transistor (IGBT) offers a low collector to emitter saturation voltage, built-in fast recovery diode (FRD), and can be used for power switching applications. It is available in a TO-247A package type.
Specification Of RBN75H65T1FPQ-A0
|
IGBT Type
|
Trench
|
|
Voltage - Collector Emitter Breakdown (Max)
|
650 V
|
|
Current - Collector (Ic) (Max)
|
150 A
|
|
Vce(on) (Max) @ Vge, Ic
|
2V @ 15V, 75A
|
|
Power - Max
|
312 W
|
|
Switching Energy
|
1.6mJ (on), 1mJ (off)
|
|
Input Type
|
Standard
|
|
Gate Charge
|
54 nC
|
|
Td (on/off) @ 25°C
|
29ns/113ns
|
|
Test Condition
|
400V, 75A, 16Ohm, 15V
|
|
Reverse Recovery Time (trr)
|
72 ns
|
|
Operating Temperature
|
175°C (TJ)
|
|
Mounting Type
|
Through Hole
|
|
Package / Case
|
TO-247-3
|
|
Supplier Device Package
|
TO-247A
|
Features Of RBN75H65T1FPQ-A0
Trench gate and thin wafer technology (G8H series)
Built-in fast recovery diode in one package
Low collector to emitter saturation voltage VCE(sat) = 1.5V typ. (at IC = 75A, VGE = 15V, Ta = 25 °C)
Quality grade: Standard
High-speed switching
Non-specification for short circuit
Applications Of RBN75H65T1FPQ-A0
UPS
Welding
Photovoltaic inverters
Power converter systems
