商品の詳細:
|
| 部品番号: | NGTB40N120FL2WG | コレクター・エミッター 電圧 VCEO マックス:: | 1.2 kv |
|---|---|---|---|
| Collector-Emitterの飽和電圧:: | 2 v | ゲートエミッター最大電圧:: | - 20ボルト、20ボルト |
| 25°Cの連続電流:: | 80 a | Pd - 消費電力:: | 535W |
| ハイライト: | 1200V IGBT Transistor,80A Integrated Circuit Chip,535W Insulated Gate Bipolar Transistor |
||
The NGTB40N120FL2WG Insulated Gate Bipolar Transistor (IGBT) features a robust and cost-effective Field Stop II Trench construction, delivering superior performance in demanding switching applications. This device combines low on-state voltage with minimal switching loss, making it ideal for UPS and solar applications. Includes a soft and fast co-packaged free-wheeling diode with low forward voltage.
| IGBT Type | Trench Field Stop |
|---|---|
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Current - Collector (Ic) (Max) | 80 A |
| Current - Collector Pulsed (Icm) | 200 A |
| Vce(on) (Max) @ Vge, Ic | 2.4V @ 15V, 40A |
| Power - Max | 535 W |
| Switching Energy | 3.4mJ (on), 1.1mJ (off) |
| Input Type | Standard |
| Gate Charge | 313 nC |
| Td (on/off) @ 25°C | 116ns/286ns |
| Test Condition | 600V, 40A, 10Ohm, 15V |
| Reverse Recovery Time (trr) | 240 ns |
| Operating Temperature | -55°C ~ 175°C (TJ) |
