商品の詳細:
|
| 部品番号: | ACPL-247-500E | チャンネル数: | 4チャンネル |
|---|---|---|---|
| 分離電圧: | 3750 Vrms | -前方流れ: | 50 Ma |
| Vf -前方電圧: | 1.4 v | Pd - 消費電力: | 170 MW |
| ハイライト: | Quad-Channel Optocoupler,3750 Vrms Isolation Voltage Optocoupler,50 mA Forward Current Phototransistor |
||
| Number of Channels | 4 |
| Voltage - Isolation | 3000Vrms |
| Current Transfer Ratio (Min) | 100% @ 5mA |
| Current Transfer Ratio (Max) | 600% @ 5mA |
| Turn On / Turn Off Time (Typ) | 3µs, 3µs |
| Rise / Fall Time (Typ) | 2µs, 3µs |
| Input Type | DC |
| Output Type | Transistor |
| Voltage - Output (Max) | 80V |
| Current - Output / Channel | 50mA |
| Voltage - Forward (Vf) (Typ) | 1.2V |
| Current - DC Forward (If) (Max) | 50 mA |
| Vce Saturation (Max) | 400mV |
| Operating Temperature | -55°C ~ 110°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.173", 4.40mm Width) |
| Supplier Device Package | 16-SO |
| Part Number | Package |
|---|---|
| AMC23C11DWV | 8-SOIC |
| TLV3605RVKR | WQFN-12 |
| TLV3012AQDBVRQ1 | SOT-23-6 |
| AMC23C10DWV | 8-SOIC |
| TLV9021QDBVRQ1 | SOT-23-5 |
| TLV1822QDGKRQ1 | VSSOP-8 |
| TLV9034QDRQ1 | 14-SOIC |
| TLV9024QDRQ1 | 14-SOIC |
| TLV3011BQDCKRQ1 | SC70-6 |
| LM339BIRTER | 16-WFQFN |
| LM339LVQDRQ1 | 14-SOIC |
| LM2901BIRTER | 16-WFQFN |
| TLV1811QDBVRQ1 | SOT-23-5 |
| TLV1811DCKR | SC-70-5 |
| TLV1811LDCKR | SC-70-6 |
| TLV1821QDBVRQ1 | SOT-23-5 |
| TLV1821LQDBVRQ1 | SOT-23-5 |
| TLV1811LQDBVRQ1 | SOT-23-5 |
| AMC23C15DWVR | SOIC-8 |
| TLV9021DBVR | SOT-23-5 |
| TLV7032QDDFRQ1 | SOT-23-8 |
| TLV1812QPWRQ1 | TSSOP-8 |
| TLV7042QDDFRQ1 | SOT-23-8 |
| TLV3811YBGR | DSBGA-6 |
| LM2901BWRTERQ1 | WQFN-16 |
| AMC21C12DENR | VSON-8 |
| TLV1812DSGR | WSON-8 |
| TLV3802DSSR | WSON-12 |
| TL391LVQDBVRQ1 | SOT-23-5 |
| TLV1822DSGR | 8-WSON |
