商品の詳細:
|
| 部品番号: | TPS7A4001DGNR | 電圧 - 入力（最大）: | 100V |
|---|---|---|---|
| 電圧ドロップアウト（最大）: | 1.3V @ 50mA | 電流 - 出力: | 50ma |
| psrr: | 65dB （100Hz） | 動作温度: | -40℃～125℃ |
The TPS7A4001DGNR is a very high voltage-tolerant linear regulator featuring a thermally-enhanced HVSSOP package, capable of withstanding continuous DC or transient input voltages up to 100V.
| Product Category | LDO Voltage Regulators |
|---|---|
| Mounting Style | SMD/SMT |
| Package / Case | MSOP-8 |
| Output Current | 50 mA |
| Number of Outputs | 1 Output |
| Polarity | Positive |
| Quiescent Current | 25 uA |
| Output Type | Adjustable |
| Minimum Operating Temperature | -40 ℃ |
| Maximum Operating Temperature | +125 ℃ |
| Dropout Voltage | 290 mV |
| Line Regulation | 0.03 %/ Vout |
| Load Regulation | 0.31 %/V |
| Operating Supply Current | 20 uA |
| Output Voltage Range | 1.175 V to 90 V |
| Power Dissipation | 833 mW |
| Part Number | Package |
|---|---|
| STM32L476RET6 | 64-LQFP |
| STM32L476JEY6 | 72-WLCSP |
| STM32L476VGT6 | 100-LQFP |
| STM32L476RCT6 | 64-LQFP |
| STM32L476QGI6 | 132-UFBGA |
| STM32L476VET6 | 100-LQFP |
| STM32L476ZET6 | 144-LQFP |
| STM32L476VGT3 | 100-LQFP |
| STM32L476VGT7 | 100-LQFP |
| STM32L476RGT6 | 64-LQFP |
| STM32L476QGI3 | 132-UFBGA |
| STM32L476ZGT3 | 144-LQFP |
| STM32L476MGY6 | 81-WLCSP |
| STM32L476RGT3 | 64-LQFP |
| STM32L476ZGT6 | 144-LQFP |
| STM32L476QEI6 | 132-UFBGA |
| STM32L476ZGJ6 | 144-UFBGA |
| STM32L476MEY6 | 81-WLCSP |
| STM32L476JGY3 | 72-WLCSP |
| STM32L486RGT7 | 64-LQFP |
| STM32L486ZGT6 | 144-LQFP |
| STM32L486RGT6 | 64-LQFP |
| STM32L486QGI6 | 132-UFBG |
| STM32L486JGY6 | 72-WLCSP |
| STM32L486VGT3 | 100-LQFP |
| STM32L486ZGT3 | 144-LQFP |
| STM32L496VGT3 | 100-LQFP |
| STM32L496VGT6 | 100-LQFP |
| STM32L496ZGT6 | 144-LQFP |
| STM32L496RGT6 | 64-LQFP |
Q. Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q: Which Certificates do you have?
A: We are ISO 9001:2015 Certified Company and member of ERAI.
Q: Can you support small quantity order or sample? Is the sample free?
A: Yes, we support sample order and small order. Sample cost is different according to your order or project.
Q: How to ship my order? Is it safe?
A: We use express to ship, such as DHL, Fedex, UPS, TNT, EMS. We can also use your suggested forwarder. Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q: What about the lead time?
A: We can ship stock parts within 5 working days. If without stock, we will confirm lead time for you based on your order quantity.
