商品の詳細:
|
| 部品番号: | NTS0104GU12 | 訳者のタイプ: | 電圧レベル |
|---|---|---|---|
| チャネルタイプ: | 双方向 | データレート: | 50Mbps |
| 回路ごとのチャネル: | 4 | 動作温度: | -40°C ~ 125°C (TA) |
The NTS0104GU12 is a 4-bit, dual supply translating transceiver with auto direction sensing that enables bidirectional voltage level translation. It features two 4-bit input-output ports (An and Bn), one output enables input (OE), and two supply pins (VCC(A) and VCC(B)).
VCC(A) can be supplied at any voltage between 1.65 V and 3.6 V, and VCC(B) can be supplied at any voltage between 2.3 V and 5.5 V, making the device suitable for translating between various voltage nodes (1.8 V, 2.5 V, 3.3 V, and 5.0 V).
| Product Category | Translation - Voltage Levels |
| Type | Dual Supply Translating Transceiver |
| Data Rate | 50 Mbps |
| Package / Case | XQFN-12 |
| Supply Voltage - Max | 5.5 V |
| Supply Voltage - Min | 1.65 V |
| Propagation Delay Time | 5.8 ns |
| Minimum Operating Temperature | -40 ℃ |
| Maximum Operating Temperature | +125 ℃ |
| Mounting Style | SMD/SMT |
| Operating Supply Current | 45 uA |
| Output Type | Tri-State |
| Power Dissipation | 250 mW |
| Part Number | Package |
|---|---|
| BGA525N6E6327XTSA1 | 6-XFDFN |
| BGA729N6E6327XTSA1 | 6-XFDFN |
| BGA7P220E6327XTSA1 | TSNP-16 |
| BGA7P320E6327XTSA1 | TSNP-16 |
| BGA725L6E6327FTSA1 | 6-XFDFN |
| BGMC1210E6327XUMA1 | VQFN-32 |
| BGAP2D30AE6327XTSA1 | TSNP-16 |
| BGAP2S20AE6327XTSA1 | TSNP-16 |
| BGAP2S30AE6327XTSA1 | TSNP-16 |
| BGAP2D20AE6327XTSA1 | TSNP-16 |
