ADS8684IDBTR Integrated Circuit Chip 500kSPS 16-Bit SAR Analog-To-Digital Converter TSSOP-38
ADS8684IDBTR Integrated Circuit Chip 500kSPS 16-Bit SAR Analog-To-Digital Converter TSSOP-38
Product Description
ADS8684IDBTR is a 4-channel, integrated data acquisition system based on a 16-bit successive approximation (SAR) analog-to-digital converter (ADC), operating at a throughput of 500 kSPS. These devices feature integrated analog front-end circuitry for each input channel with overvoltage protection up to ±20 V, a 4- or 8-channel multiplexer with automatic and manual scanning modes, and an on-chip, 4.096-V reference with low temperature drift.
Specifications
| Parameter |
Value |
| Mounting Style |
SMD/SMT |
| Package / Case |
TSSOP-38 |
| Resolution |
16 bit |
| Number of Channels |
4 Channel |
| Interface Type |
SPI |
| Sampling Rate |
500 kS/s |
| Input Type |
Single-Ended |
| Architecture |
SAR |
| Analog Supply Voltage |
4.75 V to 5.25 V |
| Digital Supply Voltage |
1.65 V to 5.25 V |
| SNR - Signal to Noise Ratio |
92 dB |
| Minimum Operating Temperature |
-40 ℃ |
| Maximum Operating Temperature |
+125 ℃ |
| Features |
Daisy-Chainable, Oscillator, Over-Voltage Protection, PGA |
| Number of Converters |
4 Converter |
| Power Consumption |
65 mW |
| SINAD - Signal to Noise and Distortion Ratio |
91.5 dB |
Key Features
- 16-Bit ADC with Integrated Analog Front-End
- 4-, 8-Channel MUX with Auto and Manual Scan
- Channel-Independent Programmable Input Ranges:
- Bipolar: ±10.24 V, ±5.12 V, and ±2.56 V
- Unipolar: 10.24 V, 5.12 V
- 5-V Analog Supply: 1.65-V to 5-V I/O Supply
- Constant Resistive Input Impedance: 1 MΩ
- Input Overvoltage Protection: Up to ±20 V
- On-Chip, 4.096-V Reference with Low Drift
- Excellent Performance:
- 500-kSPS Aggregate Throughput
- DNL: ±0.5 LSB; INL: ±0.75 LSB
- Low Drift for Gain Error and Offset
- SNR: 92 dB; THD: -102 dB
- Low Power: 65 mW
- AUX Input → Direct Connection to ADC Inputs
- SPI™-Compatible Interface with Daisy-Chain
- -40°C to 125°C Industrial Temperature Range
- TSSOP-38 Package (9.7 mm × 4.4 mm)
Applications
- Power Automation
- Protection Relays
- PLC Analog Input Modules
