商品の詳細:
|
| 部品番号: | BF776 | 電圧 - コレクターエミッタの分解（最大）: | 4.7V |
|---|---|---|---|
| 周波数 - 遷移: | 46GHz | 騒音数 (dB Typ @ f): | 0.8dB ~ 1.3dB @ 1.8GHz ~ 6GHz |
| 得: | 24dB | パワー - 最大: | 200mw |
| ハイライト: | 46GHz Transition Frequency RF Transistor,Low Noise Figure 0.8dB NPN Bipolar Transistor,High Performance Integrated Circuit Chip |
||
BF776 Integrated Circuit Chip High Performance NPN Bipolar RF Transistor PG-SOT343-3 Product Overview Of BF776 BF776 is a High Performance NPN Bipolar RF Transistor designed for superior performance in radio frequency applications. Technical Specifications Of BF776 fT 46 GHz Gmax 21.50 dB @1800 MHz IC max 50 mA NFmin 0.80 dB @1800 MHz Ptot 200 mW VCEO max 4 V Key Features Of BF776 High performance low noise amplifier Low minimum noise figure of typ. 0.8 dB @ 1.8 GHz For a
