商品の詳細:
|
| 部品番号: | SGM42500XPS8G | 動作電圧範囲: | 7V～40V |
|---|---|---|---|
| 低いオン抵抗: | 0.41Ω | ピーク出力電流: | 3.6A |
| インタフェース: | IN1/IN2 | パッケージ: | SOIC-8 |
| ハイライト: | 3.6A Peak Output Current Integrated Circuit Chip,Low On-Resistance 0.41Ω Motor Driver IC,7V to 40V Operating Voltage H-Bridge Driver |
||
SGM42500XPS8G Integrated Circuit Chip Low Power 3.6A H-Bridge Brushed DC Motor Driver SOIC-8 Product Overview Of SGM42500 The SGM42500 device is a brushed DC motor driver that integrates four N-MOSFETs, capable of supplying up to 3.6A peak current at 40V voltage. The SGM42500 supports IN1/IN2 PWM interface, allowing PWM signal implementation on the input interface to adjust motor speed. Customers can adjust PWM current limit or torque in real-time via the VREF pin using a
