商品の詳細:
|
| 部品番号: | NSM2019-100B5F3-DSWCR | 電流 - 感知: | ±100A |
|---|---|---|---|
| チャンネル数: | 1 | 感度: | 20mV/A |
| 頻度: | DC～320kHz | 直線性: | ±0.2％ |
| ハイライト: | ±100A Sensor IC,1-Channel Hall Effect Current Sensor,Bidirectional Integrated Current Sensor |
||
NSM2019-100B5F3-DSWCR Sensor IC Integrated 1-Channel Hall Effect Bidirectional Current Sensor Product Overview Of NSM2019 NSM2019 is an integrated path current sensor with a very low on-resistance of 0.27mΩ, significantly reducing heat loss on the chip. Key Features Of NSM2019 20~200A wide current range AC/DC input compatibility 3.3V/5V single power supply 0.27mΩ low input conduction impedance ±2% current measurement accuracy 1.5μs response time 320kHz signal bandwidth
